Cylinder Inboard UC168-I ( Balanced )

  • Cylinder Inboard UC168-I ( Balanced ) JPW18923

    • Suits UP28 or UP33 series helms
    • Balanced: the number of turns lock-to-lock is equal port to starboard and vice versa
    • This cylinder is recommended for use with UP28 or UP33 series helms and pre-assembled hoses
    • Nylon tubing (9.5mm) can be used as an alternative to the standard KIT-OB hose kit for plumbing the system
    Type UC168-I
    Rod Diameter 20mm
    Volume 168cc - 10.25 cubic inch
    Torque 87kg/m
    Output Force 673kg
    Inside Diameter 40mm
    Stroke 178mm
    9.5mm Fittings For high pressure flex hose
    Wheel Turns 6 turns (UP28)
    5.1 turns (UP33)
    $724.13 EA (ex. GST)
