Please note: a minimum of 10 must be purchased in any one order.
Multi-ground electrodes improve ignition capabilities and are less sensitive to increased voltage requirements due to gap growth.
Designed to specific manufacturer ignition requirements, NGK's Multi-Ground Plugs maintain all the features of their standard plugs, including corrugated ribs to prevent flashover, copper cores to aid in heat removal, and triple seals to prevent leakage.
- Trivalent metal plating
- Corrugated ribs
- Pure alumina silicate ceramic insulator
- Copper core
- Triple seals
|Shell||Specifications||Center Electrode||Ground Electrode|
|Thread Size: 12mm||Heat Range: 7||Type: V-Cut||Type: Standard|
|Hex Size: 5/8" (16mm)||Brand: NGK||Material: Nickel||Material: Nickel|
|Reach: 26.5mm (1.04")||Longevity: 30k||Size: 2.5mm||Quantity: 1|
|Seat Type: Gasket||Projection: Projected|
|Gap: .035" (0.9mm)|
|Terminal Type: Solid|
|Overall Height: ISO|
|Thread Pitch: 1.25mm|
|Resistor Value: 5K Ohm|
