Bluefin LED 4 Way Junction Box for Underwater Boat Lights JPW12401 4W-JB
$65.55 (inc. GST)
The Piranha P12 Dual-Colour Underwater Light allows you to switch between 4 different blue & white light options. Producing 6,800 fixture lumens, this light will help your boat stand out from the crowd in the marina, river or ocean.
The P12 Dual-Colour has both Cobalt Blue and Diamond White LEDs, and works as follows:
Lights are controlled via a simple on/off toggle switch or via Bluefin’s IYS Control System for MFD/mobile devices. Its ultra-compact, low-profile design is perfect for all types of boats, and is suitable for both transom & side-mounting on all hull types on boats up to 14m (45ft) long.
The P12 Dual-Colour light is also incredibly easy to install with just one small cable-entry hole and 3 mounting screws, and is suitable for a wide range of boats. This model features an AB2 bronze base.
For the number of lights your boat needs to pack a colour punch, Bluefin recommends installing 1-5 lights from the Piranha range on the transom or side of centre-console and runabout boats. Recommended spacing between the lights is from 1.2m (3ft 11 inches) to 2m (6ft 6 inches).
This light offers amazing value for money and out-performs other comparably-priced underwater lights.
Features:
If hosting a party on your boat isn’t your thing, underwater lights can be great for fishing at night where they not only make it easier to see fish in the water but also attract them to your boat! Different colours penetrate the water to varying depths. Red light can’t be seen past 5m, orange disappears at 10m, yellow at 20m, green (one of the deepest) at 30m, but blue is by far the furthest at 50m.
The human eye is sensitive to both green and blue shades so both colours stand out and are quite spectacular at night if you are looking for the fishing and party effect. Green is also a good colour in areas where the water clarity is poor. The green light will make the water appear cleaner and reflect less. However, if you usually boat in clear water, white LED lights are stunning at highlighting the beauty of the water.
How your light appears in the water will vary slightly depending on factors such as the mineral content of the water your vessel is in, how deep it is, sea floor & sediment composition, water pollution, water clarity etc.
Mounting Type: | Surface |
---|---|
Hole cut out size: | 15mm (Gland size: 13mm) |
Maximum Lamp Lumens: | 9000 |
Fixture Lumens: | 6800 |
Max Wattage: | 55 Watts |
Typical Life Expectancy: | 50,000 hours |
Voltage: | Multivolt: 12V/24V |
Power Draw: | 4.6A @ 12V / 2.35A @ 24V |
Protection: | Over / Under Voltage, Over Current, Reverse Polarity protection, Active thermal protection and Hydro block technology |
Fixture Profile: | 17.6mm |
Fixture Diameter: | 110mm |
Lens Type: | 3mm optical-grade high-impact polymer, Guard X Coating |
Fixture Material: | AB2 Bronze (standard) |
Beam Angle: | 60 Degree |
Warranty: | 2 Year |
Type Approval: | RINA IEC 60529 |
Available Colours: | Dual Colour Diamond White/Cobalt Blue |
Suitable Use: | Above & below the water-line |
Spacing: | 1.2 - 2.0m |
Driver Type: | Integral |
Total weight: | 500g |
Attached cable length: | 1.8m |
Included in box: | In-line fuse holder & rated fuse, gel connector, inline crimps, heat shrink, fixing screws, template and installation instructions |
Optional Accessories: (sold separately) |
• Junction Box: 4-way IP68-rated Wiring Junction Box • BL-Switch: Panel-mount illuminated switch & wiring loom • 220/110V Power Supply: Power supply 24V for up to 5 lights • I.Y.S Lighting Control: Control via MFD screen or mobile device |
